MiMO LTE SECTOR ANTENNA
Model : DS1727G12X65

Outdoor Installation – Integrated with Mast Mount Kit

1710～2700MHz 65° 12dBi  ±45 / X-Pol
PDF Download
X-polarized Sector Antenna 800–960MHz 15dBi 65°
Model : DS0809G15X65

Frequency: 800–960MHz, Gain: 15.3dBi; Beamwidth: 65°, Pol: X / Cross -+45°, Size: 1300×280×130mm

Marks: Antenna tilt adjustment via mechanical mount installation, Mechanical Downtilt 0-15°, provide cellular operators with significant operational and performance advantage

PDF Download
V-polarized Sector Antenna 1710–2700MHz 18dBi 90°
Model : DS1727G18V90

Frequency: 1710–2700MHz, Gain: 18dBi; Beamwidth: 90°, Pol: Vertical, Size: 1820×114×45mm

Marks: Antenna tilt adjustment via mechanical mount installation, Mechanical Downtilt 0-10°, provide cellular operators with significant operational and performance advantage

PDF Download
V-polarized Sector Antenna 1710–2700MHz 18dBi 65°
Model : DS1727G18V65

Frequency: 1710–2700MHz, Gain: 18dBi; Beamwidth: 65°, Pol: Vertical, Size: 1200×173×81mm

Marks: Antenna tilt adjustment via mechanical mount installation, Mechanical Downtilt 0-15°, provide cellular operators with significant operational and performance advantage

PDF Download
V-polarized Sector Antenna 800–2700MHz 18dBi 90°
Model : DS0827G18V90

Frequency: 800–2700MHz, Gain: 18dBi; Beamwidth: 90°, Pol: Vertical, Size: 2500×280×80mm

Marks: Antenna tilt adjustment via mechanical mount installation, Mechanical Downtilt 0-8°, provide cellular operators with significant operational and performance advantage

PDF Download
V-polarized Sector Antenna 800–2700MHz 18dBi 65°
Model : DS0827G18V65

Frequency: 800–2700MHz, Gain: 18dBi; Beamwidth: 65°, Pol: Vertical, Size: 1900×280×125mm

Marks: Antenna tilt adjustment via mechanical mount installation, Mechanical Downtilt 0-10°, provide cellular operators with significant operational and performance advantage

PDF Download
V-polarized Sector Antenna 800–2700MHz 17dBi 90°
Model : DS0827G17V90

Frequency: 800–2700MHz, Gain: 17dBi; Beamwidth: 90°, Pol: Vertical, Size: 1900×280×125mm

Marks: Antenna tilt adjustment via mechanical mount installation, Mechanical Downtilt 0-10°, provide cellular operators with significant operational and performance advantage

V-polarized Sector Antenna 800–2700MHz 16dBi 65°
Model : DS0827G16V65

Frequency: 800–2700MHz, Gain: 16dBi; Beamwidth: 65°, Pol: Vertical, Size: 1200×280×130mm

Marks: Antenna tilt adjustment via mechanical mount installation, Mechanical Downtilt 0-15°, provide cellular operators with significant operational and performance advantage

PDF Download
V-polarized Sector Antenna 800–2700MHz 15.5dBi 90°
Model : DS0827G15V90

Frequency: 800–2700MHz, Gain: 15.5dBi; Beamwidth: 90°, Pol: Vertical, Size: 1300×280×130mm

Marks: Antenna tilt adjustment via mechanical mount installation, Mechanical Downtilt 0-15°, provide cellular operators with significant operational and performance advantage

PDF Download
V-polarized Sector Antenna 800–960MHz 18dBi 65°
Model : DS0809G18V65

Frequency: 800–960MHz, Gain: 18dBi; Beamwidth: 65°, Pol: Vertical, Size: 1900×280×80mm

Marks: Antenna tilt adjustment via mechanical mount installation, Mechanical Downtilt 0-8°, provide cellular operators with significant operational and performance advantage

PDF Download
V-polarized Sector Antenna 800–960MHz 17dBi 90°
Model : DS0809G17V90

Frequency: 800–960MHz, Gain: 17dBi; Beamwidth: 90°, Pol: Vertical, Size: 2400×160×80mm

Marks: Antenna tilt adjustment via mechanical mount installation, Mechanical Downtilt 0-8°, provide cellular operators with significant operational and performance advantage

PDF Download
V-polarized Sector Antenna 800–960MHz 15dBi 65°
Model : DS0809G15V65

Frequency: 800–960MHz, Gain: 15.5dBi; Beamwidth: 65°, Pol: Vertical, Size: 1300×280×130mm

Marks: Antenna tilt adjustment via mechanical mount installation, Mechanical Downtilt 0-15°, provide cellular operators with significant operational and performance advantage

PDF Download
